Mix 6 stereo input channels, use tempo sync, discover the internal synthesizer and sequencer or use the built-in tuner. MFi compatibility even lets you connect to your iOS devices.
Smallest of its kind
TX–6 features a 6 channel stereo mixer with a configurable knob layout. Choose to have the three-band eq at your fingertips, or customize each knob to control whichever setting you prefer. With more than meets the eye, TX–6 is packed full of features and connectivity options.
6 stereo input connectors 2 stereo output connectors 1 stereo headphones connector with headset microphone support usb audio / midi interface bluetooth low energy radio interface rechargeable battery 8h battery life 48x64 pixel monochrome display
Inputs and outputs
24-bit/48kHz usb interface 3.5 mm mini jack to 6.3 mm jack headset mic input aux output connect to iPhone®, lightning cable stereo or mono for each input
Dimensions and weight
90 mm (102 mm with adapter) × 62 mm × 23 mm 160 g / 5.6 oz
audio inputs: impedance 10 kOhm analog gain 0—42 dB max level 8 dBu, 2 Vrms TLV320ADC3140 burr-brown™ SNR ~ 102 dBA
audio output (main and aux): max level 8 dBu, 2 Vrms cirrus logic masterhifi CS43131 SNR > 120 dBA
ambient working temperature:0-50°C (32-122°F)
ambient storage temperature:0-30°C (32-86°F)
clean the shell of the unit with a microfibre cloth. use pressurized air to remove dust from the faders.
to keep the battery healthy, the unit should be charged at least every 6 months. if not used for a long time, it may not charge again.
